Wall-mounted temperature transmitter（THM100-02A-YC）

The wall-mounted temperature transmitter with Output 4-20mA adopts the scientific and reasonable circuit design as well as the most advanced digital temperature sensor technology. It can turn the digital signal into the analog signal correspondingly through the central processing unit operation and analog-to-digital conversion.

Its major features are wide measuring range,small drift,long life, high precision, high cost-effective and full range of analog output as well as good linearity and stability.

Applications：Pharmaceuticl and Chemical industries, communications, environmental monitors,libraries,archives,workshops,building, supermarket and industrial automation etc.

Technical data：

Operating voltage：24VDC

Operating environment ：Humidity ≤95%RH, Temperature -20℃~80℃

Installation：wall mounted

Input signal: DS 18B20 digital sensor

Measuring range: -55~125℃

Output signal：4~20mA DC

Load capacity：≤500Ω

Power Consumption：≤2W

Product terminal pins identifications
