Wall-mounted temperature and humidity transmitter（THM100-11A-YC）

The wall-mounted temperature and humidity transmitter with Output 4-20mA adopts the scientific and reasonable circuit design as well as the most advanced digital temperature sensor technology. It can turn the digital signal into the analog signal correspondingly through the central processing unit operation and analog-to-digital conversion.

Its major features are wide measuring range, small drift, long life, high precision, high cost-effective and full range of analog output as well as good linearity and stability.

Applications：Pharmaceutical and Chemical industries,communications,environmental monitors,libraries,archives,workshops,building,supermarket and industrial Automation etc.

Technical data：

Operating voltage：24VDC

Operating environment ：Humidity ≤95%RH, Temperature -20℃~80℃

Input signal: Imported SHT series digital temperature and humidity sensor

Measuring range:-40~120℃

Output：4-20mA

Load capacity：≤500Ω
