Wall-mounted
temperature and humidity transmitter (THM300-11A-YC)
THM300-11A-YCv The wall-mounted
temperature and humidity transmitter with Output 4-20mA adopts the scientific
and reasonable circuit design as well as the most advanced digital temperature
sensor technology. It can turn the digital signal into the analog signal
correspondingly through the central processing unit operation and
analog-to-digital conversion.
Its major features are wide measuring
range, small drift, long life, high precision, high cost-effective and full
range of analog output as well as good linearity and stability.
Applications:Pharmaceutical and Chemical industries,communications,environmental
monitors,libraries,archives,workshops,building,supermarket and industrial
Automation etc.
Technical data:
Operating voltage:24VDC
Operating environment :Humidity
≤95%RH, Temperature -20℃~80℃
Input:digital temperature and humidity
sensor and digital temperature and humidity sensor 18B20
Humidity measuring range:0~100%RH
Temperature Measuring range:-55~125℃
Output:4-20mA
Load capacity:≤500Ω
