Slot RTD temperature probes(TM1109)


The Slot RTD temperature probes are used to measure the temperature of the engine coil. It is mainly used to monitor coil temperature against damage.



Technical data:

Sensor element:    Pt100, Pt500, Pt1000 meets IEC 751

Tolerance :        Class B: △t=±(0.30 + 0.005 |t| )℃

                 Class A: △t=±(0.15 + 0.002 |t| )℃

Pressure range:2.5KV or 4KV(optional)

Operating voltage: ≤60V

Operating current:≤1mA

Connecting cable:PTFE(core),  Silicone(sheath)

Measuring range:-50℃~+180℃
