TM-1111-2





Adjustable ring RTD temperature probes TM1111)(2)

Applications

The Pipeline RTD temperature probes are used to measure the temperature of pipe wall or round surface. It can be fixed with cable ties. Heat paste can be used to strengthen heat conduction. It is recommended to adopt measurements of heat preservation and insulation in case direct heat radiation affects the measure accuracy.





Technical data

Connecting cable:  PVC, temperature range:-5℃~+85℃

                Silicone, temperature range:-50℃~+180℃

                Teflon, temperature range -50℃~+260℃

                Glass Fiber, temperature range:-50℃~+350℃

Protection tube:    Stainless steel 304/316

Sensor element:    Pt100, Pt500, Pt1000 meets IEC 751

Tolerance :        Class B: △t=±(0.30 + 0.005 |t| )℃

                 Class A: △t=±(0.15 + 0.002 |t| )℃
