Type:TM1101-5-1500
Features：Traditional standard heat meter
temperature sensor pairs
Easy installation ，strong durability
Mainly
technical data：
Follow Standard：EN1413
and CJ128-2007
Measuring range：0~105℃
Matched pair accuracy：±0.1℃
Connecting cable：PVC，OD
4.2mm，2-wire
Protection tube：stainless
steel 316L，Φ5
Pressure proof PN=16bar(current speed 2m/s)
Sensor element：PT1000（PT500/PT100）
Connecting：Active
thread（copper），G：M10×1
Single sensor meets IEC751，Tolerance
Class B±（0.3+0.005|t|）℃
Each temperature sensor pair error meets
the requirement of pairing error formula：Δ（ΔT）=5mk/k×ΔT+90mk
ΔT; minimum measuring temperature
difference.Normally 3℃，But the
pairing error of each temperature sensor pair provided by BOCON is no more than
0.1℃
Resistance value at 40℃、70℃、100℃
Insulated resistance in accordance with JB/T8622-1997
(5.4)
The constant insulation resistance value
of platinum resistance should not be less than 100MΩ,the maximum upper limit of
temperature insulation resistance 10MΩ
