Applications： The Screw-in RTD temperature probes with threaded are used to measure the temperature of gases or liquids, including HVAC, Refrigeration equipments, Heaters,Ovens,Plants,Mechanical equipments and Experimental facilities,etc .

Screw-in RTD temperature probes with threaded（TM1106)

Technical data:

Connecting cable:  PVC, temperature range:-5℃~+85℃

                Silicone, temperature range:-50℃~+180℃

                Teflon, temperature range -50℃~+260℃

                Glass Fiber, temperature range:-50℃~+350℃

Protection tube:    Stainless steel 304/316, OD=4mm,5mm, 6mm,8mm

Sensor element:    Pt100, Pt500, Pt1000 meets IEC 751

Tolerance :        Class B: △t=±(0.30 + 0.005 |t| )℃

                 Class A: △t=±(0.15 + 0.002 |t| )℃

Response time：t_0.9  approx. 4secs, in water 0.2 m/sec, diameter 4mm
