Screw-in RTD temperature probes(TM1107)

	Applicatio ns： The Screw-in RTD temperature probes are mainly used for measuring temperature in mechanical equipments, including heaters, plants, mechanical equipments, generators, etc.

Technical data

Connecting cable:  Silicone, temperature range:-50℃~+180℃

                Teflon, temperature range -50℃~+260℃

                Glass Fiber, temperature range:-50℃~+350℃

Protection tube:    Stainless steel 304/316, OD=4mm,5mm, 6mm,8mm，10mm

Sensor element:    Pt100, Pt500, Pt1000 meets IEC 751

Tolerance :        Class B: △t=±(0.30 + 0.005 |t| )℃

                 Class A: △t=±(0.15 + 0.002 |t| )℃

Response time：t_0.9  approx. 10secs, in water 0.2 m/sec, diameter 6mm
